Provides methods to transfer CurveAndSurface from IGES to CASCADE. More...
#include <IGESToBRep_CurveAndSurface.hxx>
Public Member Functions | |
| IGESToBRep_CurveAndSurface () | |
| Creates a tool CurveAndSurface ready to run, with epsilons set to 1.E-04, myModeTopo to True, the optimization of the continuity to False. More... | |
| IGESToBRep_CurveAndSurface (const Standard_Real eps, const Standard_Real epsGeom, const Standard_Real epsCoeff, const Standard_Boolean mode, const Standard_Boolean modeapprox, const Standard_Boolean optimized) | |
| Creates a tool CurveAndSurface ready to run. More... | |
| void | Init () |
| Initializes the field of the tool CurveAndSurface with default creating values. More... | |
| void | SetEpsilon (const Standard_Real eps) |
| Changes the value of "myEps". More... | |
| Standard_Real | GetEpsilon () const |
| Returns the value of "myEps". More... | |
| void | SetEpsCoeff (const Standard_Real eps) |
| Changes the value of "myEpsCoeff". More... | |
| Standard_Real | GetEpsCoeff () const |
| Returns the value of "myEpsCoeff". More... | |
| void | SetEpsGeom (const Standard_Real eps) |
| Changes the value of "myEpsGeom". More... | |
| Standard_Real | GetEpsGeom () const |
| Returns the value of "myEpsGeom". More... | |
| void | SetMinTol (const Standard_Real mintol) |
| Changes the value of "myMinTol". More... | |
| void | SetMaxTol (const Standard_Real maxtol) |
| Changes the value of "myMaxTol". More... | |
| void | UpdateMinMaxTol () |
| Sets values of "myMinTol" and "myMaxTol" as follows myMaxTol = Max ("read.maxprecision.val", myEpsGeom * myUnitFactor) myMinTol = Precision::Confusion() Remark: This method is automatically invoked each time the values of "myEpsGeom" or "myUnitFactor" are changed. More... | |
| Standard_Real | GetMinTol () const |
| Returns the value of "myMinTol". More... | |
| Standard_Real | GetMaxTol () const |
| Returns the value of "myMaxTol". More... | |
| void | SetModeApprox (const Standard_Boolean mode) |
| Changes the value of "myModeApprox". More... | |
| Standard_Boolean | GetModeApprox () const |
| Returns the value of "myModeApprox". More... | |
| void | SetModeTransfer (const Standard_Boolean mode) |
| Changes the value of "myModeIsTopo". More... | |
| Standard_Boolean | GetModeTransfer () const |
| Returns the value of "myModeIsTopo". More... | |
| void | SetOptimized (const Standard_Boolean optimized) |
| Changes the value of "myContIsOpti". More... | |
| Standard_Boolean | GetOptimized () const |
| Returns the value of "myContIsOpti". More... | |
| Standard_Real | GetUnitFactor () const |
| Returns the value of " myUnitFactor". More... | |
| void | SetSurfaceCurve (const Standard_Integer ival) |
| Changes the value of "mySurfaceCurve". More... | |
| Standard_Integer | GetSurfaceCurve () const |
| Returns the value of " mySurfaceCurve" 0 = value in file , 2 = kepp 2d and compute 3d 3 = keep 3d and compute 2d. More... | |
| void | SetModel (const Handle< IGESData_IGESModel > &model) |
| Set the value of "myModel". More... | |
| Handle< IGESData_IGESModel > | GetModel () const |
| Returns the value of "myModel". More... | |
| void | SetContinuity (const Standard_Integer continuity) |
| Changes the value of "myContinuity" if continuity = 0 do nothing else if continuity = 1 try C1 if continuity = 2 try C2. More... | |
| Standard_Integer | GetContinuity () const |
| Returns the value of "myContinuity". More... | |
| void | SetTransferProcess (const Handle< Transfer_TransientProcess > &TP) |
| Set the value of "myMsgReg". More... | |
| Handle< Transfer_TransientProcess > | GetTransferProcess () const |
| Returns the value of "myMsgReg". More... | |
| TopoDS_Shape | TransferCurveAndSurface (const Handle< IGESData_IGESEntity > &start, const Message_ProgressRange &theProgress=Message_ProgressRange()) |
| Returns the result of the transfert of any IGES Curve or Surface Entity. If the transfer has failed, this member return a NullEntity. More... | |
| TopoDS_Shape | TransferGeometry (const Handle< IGESData_IGESEntity > &start, const Message_ProgressRange &theProgress=Message_ProgressRange()) |
| Returns the result of the transfert the geometry of any IGESEntity. If the transfer has failed, this member return a NullEntity. More... | |
| void | SendFail (const Handle< IGESData_IGESEntity > &start, const Message_Msg &amsg) |
| Records a new Fail message. More... | |
| void | SendWarning (const Handle< IGESData_IGESEntity > &start, const Message_Msg &amsg) |
| Records a new Warning message. More... | |
| void | SendMsg (const Handle< IGESData_IGESEntity > &start, const Message_Msg &amsg) |
| Records a new Information message from the definition of a Msg (Original+Value) More... | |
| Standard_Boolean | HasShapeResult (const Handle< IGESData_IGESEntity > &start) const |
| Returns True if start was already treated and has a result in "myMap" else returns False. More... | |
| TopoDS_Shape | GetShapeResult (const Handle< IGESData_IGESEntity > &start) const |
| Returns the result of the transfer of the IGESEntity "start" contained in "myMap" . (if HasShapeResult is True). More... | |
| void | SetShapeResult (const Handle< IGESData_IGESEntity > &start, const TopoDS_Shape &result) |
| set in "myMap" the result of the transfer of the IGESEntity "start". More... | |
| Standard_Integer | NbShapeResult (const Handle< IGESData_IGESEntity > &start) const |
| Returns the number of shapes results contained in "myMap" for the IGESEntity start ( type VertexList or EdgeList). More... | |
| TopoDS_Shape | GetShapeResult (const Handle< IGESData_IGESEntity > &start, const Standard_Integer num) const |
| Returns the numth result of the IGESEntity start (type VertexList or EdgeList) in "myMap". (if NbShapeResult is not null). More... | |
| void | AddShapeResult (const Handle< IGESData_IGESEntity > &start, const TopoDS_Shape &result) |
| set in "myMap" the result of the transfer of the entity of the IGESEntity start ( type VertexList or EdgeList). More... | |
| void | SetSurface (const Handle< Geom_Surface > &theSurface) |
| Handle< Geom_Surface > | Surface () const |
| Standard_Real | GetUVResolution () |
Detailed Description
Provides methods to transfer CurveAndSurface from IGES to CASCADE.
Constructor & Destructor Documentation
◆ IGESToBRep_CurveAndSurface() [1/2]
| IGESToBRep_CurveAndSurface::IGESToBRep_CurveAndSurface | ( | ) |
Creates a tool CurveAndSurface ready to run, with epsilons set to 1.E-04, myModeTopo to True, the optimization of the continuity to False.
◆ IGESToBRep_CurveAndSurface() [2/2]
| IGESToBRep_CurveAndSurface::IGESToBRep_CurveAndSurface | ( | const Standard_Real | eps, |
| const Standard_Real | epsGeom, | ||
| const Standard_Real | epsCoeff, | ||
| const Standard_Boolean | mode, | ||
| const Standard_Boolean | modeapprox, | ||
| const Standard_Boolean | optimized | ||
| ) |
Creates a tool CurveAndSurface ready to run.
Member Function Documentation
◆ AddShapeResult()
| void IGESToBRep_CurveAndSurface::AddShapeResult | ( | const Handle< IGESData_IGESEntity > & | start, |
| const TopoDS_Shape & | result | ||
| ) |
set in "myMap" the result of the transfer of the entity of the IGESEntity start ( type VertexList or EdgeList).
◆ GetContinuity()
| Standard_Integer IGESToBRep_CurveAndSurface::GetContinuity | ( | ) | const |
Returns the value of "myContinuity".
◆ GetEpsCoeff()
| Standard_Real IGESToBRep_CurveAndSurface::GetEpsCoeff | ( | ) | const |
Returns the value of "myEpsCoeff".
◆ GetEpsGeom()
| Standard_Real IGESToBRep_CurveAndSurface::GetEpsGeom | ( | ) | const |
Returns the value of "myEpsGeom".
◆ GetEpsilon()
| Standard_Real IGESToBRep_CurveAndSurface::GetEpsilon | ( | ) | const |
Returns the value of "myEps".
◆ GetMaxTol()
| Standard_Real IGESToBRep_CurveAndSurface::GetMaxTol | ( | ) | const |
Returns the value of "myMaxTol".
◆ GetMinTol()
| Standard_Real IGESToBRep_CurveAndSurface::GetMinTol | ( | ) | const |
Returns the value of "myMinTol".
◆ GetModeApprox()
| Standard_Boolean IGESToBRep_CurveAndSurface::GetModeApprox | ( | ) | const |
Returns the value of "myModeApprox".
◆ GetModel()
| Handle< IGESData_IGESModel > IGESToBRep_CurveAndSurface::GetModel | ( | ) | const |
Returns the value of "myModel".
◆ GetModeTransfer()
| Standard_Boolean IGESToBRep_CurveAndSurface::GetModeTransfer | ( | ) | const |
Returns the value of "myModeIsTopo".
◆ GetOptimized()
| Standard_Boolean IGESToBRep_CurveAndSurface::GetOptimized | ( | ) | const |
Returns the value of "myContIsOpti".
◆ GetShapeResult() [1/2]
| TopoDS_Shape IGESToBRep_CurveAndSurface::GetShapeResult | ( | const Handle< IGESData_IGESEntity > & | start | ) | const |
Returns the result of the transfer of the IGESEntity "start" contained in "myMap" . (if HasShapeResult is True).
◆ GetShapeResult() [2/2]
| TopoDS_Shape IGESToBRep_CurveAndSurface::GetShapeResult | ( | const Handle< IGESData_IGESEntity > & | start, |
| const Standard_Integer | num | ||
| ) | const |
Returns the numth result of the IGESEntity start (type VertexList or EdgeList) in "myMap". (if NbShapeResult is not null).
◆ GetSurfaceCurve()
| Standard_Integer IGESToBRep_CurveAndSurface::GetSurfaceCurve | ( | ) | const |
Returns the value of " mySurfaceCurve" 0 = value in file , 2 = kepp 2d and compute 3d 3 = keep 3d and compute 2d.
◆ GetTransferProcess()
| Handle< Transfer_TransientProcess > IGESToBRep_CurveAndSurface::GetTransferProcess | ( | ) | const |
Returns the value of "myMsgReg".
◆ GetUnitFactor()
| Standard_Real IGESToBRep_CurveAndSurface::GetUnitFactor | ( | ) | const |
Returns the value of " myUnitFactor".
◆ GetUVResolution()
| Standard_Real IGESToBRep_CurveAndSurface::GetUVResolution | ( | ) |
◆ HasShapeResult()
| Standard_Boolean IGESToBRep_CurveAndSurface::HasShapeResult | ( | const Handle< IGESData_IGESEntity > & | start | ) | const |
Returns True if start was already treated and has a result in "myMap" else returns False.
◆ Init()
| void IGESToBRep_CurveAndSurface::Init | ( | ) |
Initializes the field of the tool CurveAndSurface with default creating values.
◆ NbShapeResult()
| Standard_Integer IGESToBRep_CurveAndSurface::NbShapeResult | ( | const Handle< IGESData_IGESEntity > & | start | ) | const |
Returns the number of shapes results contained in "myMap" for the IGESEntity start ( type VertexList or EdgeList).
◆ SendFail()
| void IGESToBRep_CurveAndSurface::SendFail | ( | const Handle< IGESData_IGESEntity > & | start, |
| const Message_Msg & | amsg | ||
| ) |
Records a new Fail message.
◆ SendMsg()
| void IGESToBRep_CurveAndSurface::SendMsg | ( | const Handle< IGESData_IGESEntity > & | start, |
| const Message_Msg & | amsg | ||
| ) |
Records a new Information message from the definition of a Msg (Original+Value)
◆ SendWarning()
| void IGESToBRep_CurveAndSurface::SendWarning | ( | const Handle< IGESData_IGESEntity > & | start, |
| const Message_Msg & | amsg | ||
| ) |
Records a new Warning message.
◆ SetContinuity()
| void IGESToBRep_CurveAndSurface::SetContinuity | ( | const Standard_Integer | continuity | ) |
Changes the value of "myContinuity" if continuity = 0 do nothing else if continuity = 1 try C1 if continuity = 2 try C2.
◆ SetEpsCoeff()
| void IGESToBRep_CurveAndSurface::SetEpsCoeff | ( | const Standard_Real | eps | ) |
Changes the value of "myEpsCoeff".
◆ SetEpsGeom()
| void IGESToBRep_CurveAndSurface::SetEpsGeom | ( | const Standard_Real | eps | ) |
Changes the value of "myEpsGeom".
◆ SetEpsilon()
| void IGESToBRep_CurveAndSurface::SetEpsilon | ( | const Standard_Real | eps | ) |
Changes the value of "myEps".
◆ SetMaxTol()
| void IGESToBRep_CurveAndSurface::SetMaxTol | ( | const Standard_Real | maxtol | ) |
Changes the value of "myMaxTol".
◆ SetMinTol()
| void IGESToBRep_CurveAndSurface::SetMinTol | ( | const Standard_Real | mintol | ) |
Changes the value of "myMinTol".
◆ SetModeApprox()
| void IGESToBRep_CurveAndSurface::SetModeApprox | ( | const Standard_Boolean | mode | ) |
Changes the value of "myModeApprox".
◆ SetModel()
| void IGESToBRep_CurveAndSurface::SetModel | ( | const Handle< IGESData_IGESModel > & | model | ) |
Set the value of "myModel".
◆ SetModeTransfer()
| void IGESToBRep_CurveAndSurface::SetModeTransfer | ( | const Standard_Boolean | mode | ) |
Changes the value of "myModeIsTopo".
◆ SetOptimized()
| void IGESToBRep_CurveAndSurface::SetOptimized | ( | const Standard_Boolean | optimized | ) |
Changes the value of "myContIsOpti".
◆ SetShapeResult()
| void IGESToBRep_CurveAndSurface::SetShapeResult | ( | const Handle< IGESData_IGESEntity > & | start, |
| const TopoDS_Shape & | result | ||
| ) |
set in "myMap" the result of the transfer of the IGESEntity "start".
◆ SetSurface()
| void IGESToBRep_CurveAndSurface::SetSurface | ( | const Handle< Geom_Surface > & | theSurface | ) |
◆ SetSurfaceCurve()
| void IGESToBRep_CurveAndSurface::SetSurfaceCurve | ( | const Standard_Integer | ival | ) |
Changes the value of "mySurfaceCurve".
◆ SetTransferProcess()
| void IGESToBRep_CurveAndSurface::SetTransferProcess | ( | const Handle< Transfer_TransientProcess > & | TP | ) |
Set the value of "myMsgReg".
◆ Surface()
| Handle< Geom_Surface > IGESToBRep_CurveAndSurface::Surface | ( | ) | const |
◆ TransferCurveAndSurface()
| TopoDS_Shape IGESToBRep_CurveAndSurface::TransferCurveAndSurface | ( | const Handle< IGESData_IGESEntity > & | start, |
| const Message_ProgressRange & | theProgress = Message_ProgressRange() |
||
| ) |
Returns the result of the transfert of any IGES Curve or Surface Entity. If the transfer has failed, this member return a NullEntity.
◆ TransferGeometry()
| TopoDS_Shape IGESToBRep_CurveAndSurface::TransferGeometry | ( | const Handle< IGESData_IGESEntity > & | start, |
| const Message_ProgressRange & | theProgress = Message_ProgressRange() |
||
| ) |
Returns the result of the transfert the geometry of any IGESEntity. If the transfer has failed, this member return a NullEntity.
◆ UpdateMinMaxTol()
| void IGESToBRep_CurveAndSurface::UpdateMinMaxTol | ( | ) |
Sets values of "myMinTol" and "myMaxTol" as follows myMaxTol = Max ("read.maxprecision.val", myEpsGeom * myUnitFactor) myMinTol = Precision::Confusion() Remark: This method is automatically invoked each time the values of "myEpsGeom" or "myUnitFactor" are changed.
